Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace

Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace

Product Details

Place of Origin: Henan, China

Brand Name: HT

Model Number: Chrome Corundum Brick

Payment & Shipping Terms

Price: $3,500.00 - $6,000.00/metric tons

Get Best Price

Product Details

Product Description
Highlight:
Shape:
Brick
Material:
Chrome And Corundum
SiO2 Content (%):
0
Al2O3 Content (%):
5 ~ 88, Customizable
MgO Content (%):
0
CaO Content (%):
0
Refractoriness (Degree):
1770°< Refractoriness< 2000°
CrO Content (%):
50~ 94, Customizable
SiC Content (%):
0
Processing Service:
Bending, Welding, Punching, Decoiling, Cutting, Moulding
Product Name:
High Temperature Chrome Refractory Bricks For Glass Kilns
Raw Material:
Chrome And Corundum
Bulk Density (g/cm3):
3.30 ~ 3.65 G/cm3
Refractoriness (°C):
> 1770 °C
Refractoriness Under Load (0.2Mpa/℃):
> 1700 °C
Cold Crushing Strength (MPa):
>100
Apparent Porosity (%):
≤17
Certificate:
ISO9001:2000
Usage:
Blast Furnace, Glass Kiln, Cement Kiln And So On
Keyword:
High Chrome Brick
Shape:
Brick
Material:
Chrome And Corundum
SiO2 Content (%):
0
Al2O3 Content (%):
5 ~ 88, Customizable
MgO Content (%):
0
CaO Content (%):
0
Refractoriness (Degree):
1770°< Refractoriness< 2000°
CrO Content (%):
50~ 94, Customizable
SiC Content (%):
0
Processing Service:
Bending, Welding, Punching, Decoiling, Cutting, Moulding
Product Name:
High Temperature Chrome Refractory Bricks For Glass Kilns
Raw Material:
Chrome And Corundum
Bulk Density (g/cm3):
3.30 ~ 3.65 G/cm3
Refractoriness (°C):
> 1770 °C
Refractoriness Under Load (0.2Mpa/℃):
> 1700 °C
Cold Crushing Strength (MPa):
>100
Apparent Porosity (%):
≤17
Certificate:
ISO9001:2000
Usage:
Blast Furnace, Glass Kiln, Cement Kiln And So On
Keyword:
High Chrome Brick
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace
Product Description
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 0
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 1
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 2
High chromium bricks
Refractory high chromium bricks are made of corundum and molten chromium oxide as the main raw materials, plus fine Powder and other additives, kneaded. Drying at high temperature in shuttle kiln, high chromium brick has good thermal stability and high temperature creep performance. High chromium bricks are made of industrial grade chromium trioxide and alumina as the main raw materials, or introduce a small amount of zirconia, etc., after high temperature firing, the content of chromium trioxide is not less than 75%, chromium trioxide, alumina and Shaped refractory products with a total content of zirconia not less than 98%. It hasexcellent corrosion resistance, high compressive strength at room temperature, high strength at high temperature, excellent wear resistance, high refractoriness, excellent thermal shock resistance, and good volume stability at high temperatures.
ltem
High chrome
oxide brick
Middle chrrome oxide brick
80 Chorme Bricks
70 Chorme Bricks
60 Chorme Bricks
50 Chorme Bricks
Cr2O3 %
≥93%
≥80%
≥70%
≥60%
≥50%
Apparent Porosity
≤16%
≤16%
≤16%
≤16%
≤16%
Bulk Density
g/cm3
≥4.25
≥4.1
≥3.7
≥3.6
≥3.5
Cold crushing
strength Mpa
≥100 Mpa
 ≥120 Mpa
≥120 Mpa
≥120 Mpa
≥120Mpa
Refractoriness
underload
(0.2MPa,0.6%)
≥1700°C
≥1700°C
≥1700°C
≥1700°C
≥1700°C
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 3

Project case of high chrome bricks

With excellent performance and corrosion Resistance , high chrome bricks is widely used together with AZS bricks in the glass kilns, here it is used for glass furnace throat.
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 4
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 5
Product Presentation

Features of isostatic chrome brick
(1) Excellent resistance to slag erosion.
The Cr2O3 material itself has excellent resistance to slag erosion, which is mainly due to the following points: 1) The solubility of Cr2O3 in coal slag is very low, thus ensuring the integrity of the material; 2) Most of the slag has an effect on Cr2O3 materials. The wettability is poor, thereby delaying the dissolution of Cr2O3 in the slag; 3) The dissolution of Cr2O3 material in the slag will increase the viscosity of the slag, and even form a uniform protective layer on the surface of the material to block the pores of the material and inhibit Slag penetration.
(2) Excellent high temperature performance.
The main components of high chromium bricks, Cr2O3, Al2O3, and ZrO2, have melting points of approximately 2400, 2050, and 2700℃, respectively. After 1700t high temperature treatment, Cr2O3 and Al2O3 form a well-crystallized and continuous aluminum-chromium solid solution, so high-chromium refractory The material has high high temperature strength.
(3) Excellent anti-erosion performance.
The formation of aluminum chromium solid solution and the sintering effect of ZiO2 make high chrome materials have lower apparent porosity and higher compressive strength (up to 150 MPa or even more than 200 MPa), so high chromerefractories have good resistance Scouring performance.
(4) Thermal shock resistance and thermal peeling resistance.
Due to the phase change toughening effect of ZrO2, the thermal shock resistance and thermal exfoliation resistance of high chrome refractories are improved.
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 6
Application Scenarios
High chrome brick is used in the production of chemical plants, chemical kilns, and alkali-free glass fiber kilns. The key part of waste incinerators and glass furnace.

High chrome bricks used in Glass industryz

Using higher grade refractory materials like high chrome brick in key part is an effective way to increase the overall service life of the Resistance to alkali and glass liquid erosion of Chrome bricks is better than that of AZS, it can replace AZS block in the key part, like corner brick of the dog house, barrier, bubbling area, cover brick and throat etc. ......to gain a better performance.
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 7
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 8
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 9
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 10

Orther industry

Steel Industry: It is used in metallurgical furnaces, electric furnaces, open hearth furnaces with the most severe slag corrosion location, for example, the AOD furnace air eye area of the external refining device, RH furnace vacuum chamber lower groove and impregnation tube, VOD slag Line, etc.
Non-Ferrous Metals: This refractory block is used for non ferrous metallurgical (copper,lead, tin, nickel, etc.) , like converter air outlet area, flash furnace reaction tower, sedimentation tank, anode slag line position, alkaline refractory material kiln high-temperature zone, etc.
Chemical Industry: High-chrome bricks are used in various high-temperature chemical reactors, including those for ammonia synthesis, synthetic rubber production, coal chemical processing,and other chemical processes. They are primarily used in the ammonia synthesis towers, heat exchangers, pipelines in ammonia synthesis plants, reactors, separators, and pipelines in synthetic rubber plants, and so on.
Power Industry: High-chrome bricks are used in waste incineration furnaces and other high-temperature reactors in the power industry.
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 11
Certificate
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 12
1. Strong professional:
Our company has thirty years producing experience in refractory products. Our manager will supervise on a various refractorys production materials, process control, quality supervision and package delivery, and ensure the products are 100% qualified.
2.Annual supply:
Our company has passed ISO9001 quality management system certification and SGS certification. And the annual supply of shaped and unshaped refractory product is 28, 800-35, 000 tons.
3.Export experiences:
Now we have gained a global sales network reaching Korea, Vietnam, USA, Mexico, French, India, South Africa, and so on.
4. Production equipment:
Production and testing equipments are new, complete and automated or semi- automated. Such modern facilities and equipments have provided the fine technical guarantee for the production and testing.
5. Testing equipment:
Our company's testing equipments as follows:
High Temperature RUL Tester
Bulk Density Tester
The Pressure Tester
Refractoriness Tester

Our competitive Advantage:
1.Competitive Price: Make the products competitive in your market.
2.Quick Response:We promise quick response at the very first moment when we received your request. 3.Superior 3.Customer Service:Thecompany provides after sales service ensuring customer’s satisfactions,we believe in Long term partnership bringing loyalty.
4.We had been on this filed for many years and we have our own research team,the prouduction process could be concrolled strictly.
5.We have developed stable customer base overseas and kept long-term cooperation.
Related products
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 13
Workshop corner
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 14
Packing&Shipping
Packaging
1. 1 ton bags in container, 25 MT/20'FCL.
2. 25kg bags in container, 25 MT/20'FCL
3. 25kg bags in ton bags, then in container, 25 MT/20'FCL
4. as the customer' request
For high chrome brick details:
Pallet+Paper or Steel angle bead+Paper board +Plastic or Steel belt +Plastic film
(1)Wooden pallet size:Usually0.92*0.92m(standard brick),but 1*1m (special shape brick)at most,
(2)Load weight of each pallet:Usually 1.5-1.7Tons,but 2.0 Tons at most.
(3)20 Foot Container can be loaded 25-26Tons at most,about 13-16Pallets.
(4).Can make the package according to customer's requirements.
Delivery:
15-30 days working day for large quantity. The shipment we will arrange as soon as possible. Of course, if it is a custom products, the shipping time will delay.
Sample:
Usually by EMS, DHL, UPS, TNT, FedEx. Anyway you like. Bulk order: Usually by sea.
Payment:
It can be through T/T, L/C at sight. The specific terms determined according to the quantity of the goods, etc.
Processing Service Bending High Chrome Refractory Brick for Glass Fiber Furnace 15
FAQ
Q1. Are you Manufacturer?
A: Yes, of course, our factory is in Xinmi city, Henan province.
Q2. Can we visit your company?
A: Sure,welcome at any time, seeing is believing.
Q3. Do you accept OEM?
A: Yes, we can do OEM.
Q4. What's the MOQ of trial order?
A: No limit, we can offer the best suggestions and solutions according to your condition.
Q5. What are the payment terms?
A: Usually T/T, but L/C, Western Union etc are available for us.
Q6. How long is delivery time?
A: The delivery time usually depends on the order quantity, usually around 15-25 days.

Tags:

glass furnace refractory,

refractory bricks,

refractory fire brick

Similar Products
Sintered Zircon Brick for Durable High Temperature Stability and Anti-Wear Properties Video

Sintered Zircon Brick for Durable High Temperature Stability and Anti-Wear Properties

Get Best Price
ISO9001 2008 Certified High Alumina Refractory Brick for Glass Furnace 50% 60% 70% 80% Video

ISO9001 2008 Certified High Alumina Refractory Brick for Glass Furnace 50% 60% 70% 80%

Get Best Price
Cold Crush Strength Min 60 Mpa Alumina Refractory Bricks Glass Furnace Materials Video

Cold Crush Strength Min 60 Mpa Alumina Refractory Bricks Glass Furnace Materials

Get Best Price
International Standard Alumina Refractory Brick for Lining Sk34 Brick Glass Furnace Video

International Standard Alumina Refractory Brick for Lining Sk34 Brick Glass Furnace

Get Best Price
High Alumina Content % International Standard Lining Sk34 Brick for Glass Furnace Video

High Alumina Content % International Standard Lining Sk34 Brick for Glass Furnace

Get Best Price
Glass Melting Furnace Height High Density Alumina Lining Bricks with Zirconia Raw Material Video

Glass Melting Furnace Height High Density Alumina Lining Bricks with Zirconia Raw Material

Get Best Price
Alumina Silica Brick for Temperature Acid Resistance in Glass Kiln and Coke Oven Video

Alumina Silica Brick for Temperature Acid Resistance in Glass Kiln and Coke Oven

Get Best Price
Alumina Fireproof Bricks for Converter Furnace 3.84 Bulk Density International Standard Video

Alumina Fireproof Bricks for Converter Furnace 3.84 Bulk Density International Standard

Get Best Price
High Strength Alumina Chrome Spinel Brick for High Temperature Glass and Cement Kiln Video

High Strength Alumina Chrome Spinel Brick for High Temperature Glass and Cement Kiln

Get Best Price
Chrome Refractory Brick with SiO2 Content Meeting International Standard Video

Chrome Refractory Brick with SiO2 Content Meeting International Standard

Get Best Price
Customized Size Fire Resisting Brick High Chromium Brick for Industrial Furnaces Video

Customized Size Fire Resisting Brick High Chromium Brick for Industrial Furnaces

Get Best Price
Henan Hongtai Kiln Refractory Co.,Ltd.
products

High Alumina Brick

AZS Refractory Bricks

Fire Clay Brick

Silica Refractory Bricks

Magnesia Refractory Bricks

Insulation Refractory Bricks

Acid Proof Brick

sales@ht-refractory.com 86--18135687808
Group 4, Chuling Village, Chaohua Town, Zhengzhou, Henan, China
Quick links
Company Profile Factory Tour Quality Control news Cases Sitemap Privacy Policy
China Good Quality High Alumina Brick Supplier. Copyright © 2024-2025 Henan Hongtai Kiln Refractory Co.,Ltd. . All Rights Reserved.
